PSA nitrogen generator price

PSA nitrogen generator price

PSA nitrogen generator price
PSA nitrogen generator pricePSA nitrogen generator price
CategoriesPSA Nitrogen generator
AlbumView larger image
BrandKL gas generator
ModelKPN49-55
Product NamePSA nitrogen generator price
BrandKL
Model numberKPN49-55
Warranty12 months
After-sales Service ProvidedEngineers available to service machinery overseas
TechnologyPSA
Dew point≤-40℃
Outlet pressure0.6-0.8MPa(Adjustable)
Unit PriceUS $ 10000-70000 / piece
FOB portShanghai or Ningbo port, or other China sea port
Terms of PaymentL/C, T/T
Download DOC
Update Time2019-11-21
Detail Information

PSA nitrogen generator price

Comprehensive presentation:


PSA nitrogen generator price Features:

* Low investment, small workload of construction;

* Low energy consumption, advanced process system;

* High automation, less operators;

* Quickly start, and conveniencely open and shut down;

* Low costs of maintenance;

* Stable operation and highly reliable;

* High quality pneumatic control valves, safe, reliable and durable;

* High quality special carbon molecular sieve adsobent, good adsorption properties.

How it works ?

Under a certain pressure, using the large difference of the diffusion rate between nitrogen and oxygen from the air in the carbon molecular sieve, a large number of oxygen is adsorpted by carbon molecular sieve, while nitrogen is collected in a short time, to achieve separation of oxygen and nitrogen.


The adsorption capacity of carbon molecular sieve is significantly different with different oxygen

pressures, reducing the pressure will release oxygen from carbon molecular sieve, this make carbon molecular sieve regeneration, then can be used repeatedly.Using two adsorption towers, one for adsorption and nitrogen generator, the other for desorption and recycling.


They switch with each other, thus continuous output of high-quality nitrogen.


Flow Chart:

1.Air compressor one set

2.Compressed air pretreatment system (dryer and multistage filters) one set

3.Air buffer tank one set

4.PSA oxygen generator one set

5.Oxygen gas buffer tank one set

6.Oxygen booster one set

7.Filling station one set

8.Control system one set (including man-machine control interface)

9.Instrument and meter (installed in nitrogen generator) one set



PSA nitrogen generator price purity 99.99% Specifications:


Model

capacity(Nm3/h)

Air consumption(Nm3/min)

inlet connection(DN)mm

outlet connection(DN)mm

Buffer tank

Dimension(L*W)mm

KPN49-5

5

0.5

15

15

CG-0.5

KPN49-10

10

1

15

15

CG-0.5

1650*1050

KPN49-20

20

2

25

15

CG-0.5

1850*1100

KPN49-30

30

3

32

15

CG-1

1950*1200

KPN49-40

40

4

40

20

CG-1

2100*1250

KPN49-50

50

5

40

20

CG-1.5

2250*1350

KPN49-60

60

6

50

20

CG-1.5

2300*1380

KPN49-80

80

8

50

25

CG-2

2550*1500

KPN49-100

100

10

50

25

CG-3

2750*1650

KPN49-150

150

15

65

25

CG-4

3100*1850

KPN49-200

200

20

80

30

CG-5

3560*2100

KPN49-300

300

30

80

40

CG-6

3950*2250

KPN49-400

400

40

100

50

CG-8

4100*2550

KPN49-500

500

50

125

50

CG-12

4300*2750

KPN49-600

600

60

125

65

CG-15

4550*2950

KPN49-800

800

80

150

65

CG-20

5250*3050

KPN49-1000

1000

100

200

80

CG-25

4550*5350


Factory and showroom:





PSA nitrogen generator price Package & Shippment:


Delivery time
Generally 50 working days after the order confirmed

Packaging
1) Custom package request is appreciate.
2) Standard package: Skid-mounted standard export package


FAQ:

1. Are you manufacturer or Trade Company?
We are OEM professional factory, founded in 1997.

2. What's the order process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Printing file--- PDF, Ai, CDR, PSD, the picture resolution must be at least 300 dpi.
d. Contract confirmation---provide correct contract details.
e. Payment terms--- T/T 30% in advanced, balanced before shipment.
f. Production---mass production
g. Shipping--- by se,. detailed picture of package will be provided.

h.Installation and commissioning ---If customer need, we will send our engineer guide on-site installation and commission.

3.What terms of payment you use?

T/T, L/C.

4. Do you have any instant chat tool?

Alice Qiao

Hangzhou Kelin Aier Qiyuan Equipment Co.ltd

Anxi Industrial Zone,Liangzhu,Yuhang,Hangzhou,China

Mobile:+86-18357045966

Tel :+86-0571-88790788

Fax::+86-0571-88792222

Email:cg2013(at)klqy.com

Skype: alice.qiao19


when you kind sending the inquiry to us,pls kindly send it with below  information.


Technical Information

Your kind requirment

                           1).N2 Flow Rate

                                   _____Nm3/hr

                           2).N2 Purity

                                    _____%

                           3).N2 Discharge Pressure

                                    _____Bar

                           4).Voltages and Frequency

                                    _____V/P/Hz

                           5).N2 Application
